Name: CC30 Cc 30 Series
SKU: 542
Price: 980.00 GBP
Availability: InStock

The CC30 Series Column Cap is a heavy-duty structural connector engineered to provide a secure, high-capacity load-transfer connection between timber beams and wood or steel support posts. Designed for demanding residential, commercial, and industrial construction applications, this series ensures superior lateral resistance and structural alignment at critical post-to-beam intersections.

Product Description

Manufactured from high-tensile structural steel, the CC30 Series provides a robust metal housing that firmly encompasses both the supporting column and the horizontal beam. The engineered design features precisely located bolt holes to accommodate heavy-duty structural bolts, ensuring uniform load distribution and reducing the risk of wood splitting or structural connection failure under severe environmental loads.

The connector is finished with protective coatings engineered to withstand harsh Canadian weather conditions, preventing corrosion from moisture, humidity, and atmospheric exposure. Ideal for both indoor structural framing and exposed outdoor wood constructions, the CC30 Series delivers long-term durability, simplified installation, and strict compliance with standard building code load requirements.

Key Applications

Support post-to-beam connections in heavy timber construction
Structural framing for decks, pergolas, porticos, and covered patios
Commercial timber framing and wood truss support systems
Residential basement beam-to-column support connections
Industrial wood shelter framing and agricultural post-frame structures

Specifications

Series Name: CC30 Series
Product Type: Structural Column Cap / Post-to-Beam Connector
Material Construction: Heavy-gauge structural steel (ASTM A653 / ASTM A36 equivalent)
Protective Finish: Hot-Dip Galvanized (HDG) / Exterior Powder Coated / Standard Grey Primer
Fastener Type: Structural bolts (through-bolt configuration)
Corrosion Resistance: High resistance to moisture, humidity, and outdoor atmospheric elements
Structural Function: Dual-direction load distribution (vertical gravity loads and horizontal lateral resistance)
Code Compliance: Designed in accordance with standard National Building Code (NBC) load-bearing criteria
Compatibility: Engineered for standard dimensional lumber, glulam beams, and heavy timber posts
